Flexible Charging Pile

Product

360KW Flexible Charging Pile

EV Charging Accessories

List price:0.00

Price:0.00

<p>Super power output;Flexible power distribution, enhancing the equipment utilization, reduced the initial investment cost;Mointoring and protection systems ensure the safety when the mechine is running;Automatically choosing the correct power level for each model’s battery;Built for any environment, thriving in temperatures from -20°C to +65°C,over 50℃ decrating input<br/><br/>Type：AF-DC-360KW(separated type) <br/>Input Volte：323-437Vac <br/>Input Frequency：45~65Hz <br/>Maximum Input Current：720A <br/>Input Power Factor：≥0.99 <br/>Output Voltage Range：200~750Vdc <br/>Output Current Range：0~1080A(System） <br/>Machine Efficiency：Peak Efficiency≥95% <br/>Operating Temperature：-20~65℃，over 50℃ decrating input<br/> Operating Humidity：≤95% <br/>Altitude：≤2000m <br/>Protecting Function：GB/T 20234.2-2015 <br/><br/><br/></p>

Send Your Inquiry
